Application Based Quick Couplings

high-pressure-ball-valves

Application Based Quick Couplings

We offer precision turned high quality Quick Couplings. These products are widely appreciated for its quality, durability and outstanding performance. We also offer customization services on our range as per the client’s specifications. Our range of quick couplings are as under:

  • Double shut off coupling or Two way shut off coupling. QRC-VV Series is a general purpose double shut off type coupling of this range
  • High pressure hydraulic coupling HD Series couplings are used for such applications
  • Single shut off or one way shut off couplings. SV series and NV series are single shut off type quick couplings. it is widely used in industrial pneumatic applications
application-based-quick-coupling
  • Straight through coupling. This type of quick coupling is suited for thick, viscous and semi-solid type of fluid like gum,paste, grease. ST series coupling is a straight through type of quick coupling
  • Flat face quick coupling These type of quick couplings are ideal for mobile hydraulics application. it prevents contamination of hydraulic fluids.
  • Screw coupling These type of quick couplings are for high pressure hydraulics in static application. The coupler and Adaptor as secured through a screw threads to withstand high pressure of the system.

few of our samples are listed here which are based upon the application as specified by the user

  • Quick coupling for solvant transfer
  • Quick coupling for engine testing
  • Quick coupling for bulk material transfer
  • Quick coupling for injection molds
  • Quick coupling for hazardous liquid
Quick Coupling For Hazardous Fluids

Quick Coupling For Hazardous Fluids are mainly used for industrial applications. Any spillage/leakage during tanker unloading or refilling is harmful for the operator. Hence for bulk material transfer these coupling is ideal choice

The main features of bulk material transfer couplings are:

  • Quick connection without use of tools
  • No spill
  • Full flow
  • No leakage
  • Minimize material loss during transfer
  • Easy and safe to operate
  • Eliminates costly clean-ups
application-based-quick-coupling

End connections: Different choice of end connection like threaded ends, weld ends and flanged ends are available depending upon user requirements.

Use of bulk material transfer coupling ensures that loading arm or hoses are connected without spillage.

CNG Couplings

We offer quick CNG Couplings for CNG applications. These CNG fueling coupling are available with following features.

Features:

  • Sizes: 1/4" - 1"
  • MOC: Brass, stainless steel
  • End conn: NPT, BSP female threads
application-based-quick-coupling
Mold Couplings

We manufacture high quality quick coupling for injection used for plastic injection molding components. Mould Couplings are used for connecting injection moulding dies in shortest possible time. The use of quick coupling prevent leakage of coolant and increases output. Mould coupling are especially designed for frequent connection and disconnection of coolant lines for change over of dies in injection molding industry.

The features of mould couplings are :

  • Size: 1/8" - 1"
  • Material: brass, stainless steel, carbon steel
  • End connection: threaded and hose shank
  • Type: with and without shut off valve
  • Temp: working upto 180°C

Other Information :

  • Pay Mode Terms: Other
application-based-quick-coupling

End connections: Different choice of end connection like threaded ends, weld ends and flanged ends are available depending upon user requirements.

Use of bulk material transfer coupling ensures that loading arm or hoses are connected without spillage.

Quick Coupling For Engine Testing

We are offering Quick Coupling for Engine Testing. This type of quick connect coupling is designed especially for automotive industry for testing of engine on a test bench. Engine Testing Coupling is offered in 6NB, 8NB, 10 NB pipe size with different end connection.

Advantage of using quick coupling :

  • Avoids loss of fuel during testing
  • Reduces set up and test time per unit
  • Fast and easy operation
  • Low maintenance
application-based-quick-coupling
Material Transfer Coupling

We deal in coupling for solvent & bulk material transfer. We offer Material Transfer Coupling along with hose fittings for transfer and handling various liquids for process industry. We specialize in handling solvents, API fluids. Our customized solution includes non interchangeable end fittings to avoid mixing of different liquids.
